Facilities

LVD CNC Laser Cutting Machine

• Max. processing size
- 4000mm x 2000mm x 290mm

• Max. processing thickness
- Mild steel 16mm
- Stainless steel 12mm
- Aluminium 6mm

Strippit CNC Turret Punching Machine

• Press capacity
- 25 tons

• Sheet size capacity
- 1220mm x 2440mm

YSD CNC Press Brake Machine

• Axis
- 5 axis

• Bending force
- 80 tons

• Usable length
- 2500mm

Darley Hydraulic Shearing Machine

• Max. length
- 3050mm

• Max. thickness
- 6.5mm

Kuka Robot C/W Plasma Welding

• Drive units for 6 degrees of freedom

• Repeatable better than 0.1mm

• 1412 reachable, measurable at center of 5th axis

CNC Plasma Cutting Machine

• Max. length
- 6000mm

• Max. thickness
- 30mm

CNC Grooving Machine

• Processing thickness
- 0.6 - 4mm

• Processing length
- 4000mm

• Processing width
- 1220mm

Hydraulic Uncoiling Machine

• Max. weight
- 5 tons

• Max. width
- 1500mm

Kumla Plate Bending Machine

• Max. length
- 2500mm

• Max. thickness
- 15mm

• Roll diameter
- 295mm

Round Pipe Rolling Machine

• Rolling diameter of tube
- 19.1 - 76.1mm

Hefeng Hydraulic Pipe Bending Machine

• Range of bending radius
- 50 - 300mm

• Bending diameter of steel tube
- 19.1 - 50.8mm

Plate Grinding Machine

• Processing thickness
- 0.3mm

• Processing width
- 300 - 1550mm

• Grinder type
- 4 heads type

CNC Single Arm 2-axis Milling Machine

• Processing size
- 6000mm (L) x 2600m (W)

Kuraki Multi-tasking CNC Milling Machine

• Processing size
- 1500mm (L) x 650mm (W)

Lathe Machine

• Processing size
- 10 - 120mm (Dia)
